| Model | TWS15 | TWS18 | TWS22 | TWS28 |
| Split Force | 15t | 18t | 22t | 28t |
| Log Capacity | 630mm | 630mm | 630mm | 630mm |
| Max working pressure | 25MPa | 25MPa | 25MPa | 25MPa |
| Cylinder inner diameter | 3Inch | 3.5Inch | 4Inch | 4.5Inch |
| Hydraulic Rod Diameter | 44.5mm | 44.5mm | 44.5mm | 44.5mm |
| Hydraulic Cylinder Stroke | 600mm | 600mm | 600mm | 600mm |
| Cylinder Cycle Time | 9S | 12S | 15S | 18S |
| Size of cleaver | 180mm | 180mm | 180mm | 180mm |
| Tractor-mounted | CAT 1，CAT 2 | CAT 1，CAT 2 | CAT 1，CAT 2 | CAT 1，CAT 2 |
| Max Flow | 41.6L/min | 41.6L/min | 41.6L/min | 41.6L/min |
| Overall dimensions | 1920*985*705mm | 1920*985*705mm | 1920*985*705mm | 1920*985*705mm |
